CERAKOTE

MC-5100 | Clear - Aluminum

€39,00
€39,00
€330,51 l
Shipping will be calculated at checkout

The prices include import duties and handling, but exclude the VAT applicable in your country.

Hazardous material: UN number 1993, hazard class 3

  • American Express
  • Apple Pay
  • EPS
  • Google Pay
  • Maestro
  • Mastercard
  • PayPal
  • Union Pay
  • Visa
  • Official Distributor
  • Worldwide Sale & Shipping
  • 1-5 Days Express Shipping

Documents

Safety Data Sheet
Application Guide

Questions about the product?

We are happy to help.

Cerakote Clear - Aluminium MC-5100 was specifically developed for use on all common aluminum alloys, including magnesium alloys. Typical applications include polished, brushed, and raw aluminum used in architecture, automotive, industry, consumer goods, and much more. Click here to find the optimal Cerakote Clear Coat for your application.

  • Easy to apply, ready to use, can be applied directly to aluminum
  • Surface preparation is simple with detergent and water
  • Preserves the natural aluminum appearance while protecting against oxidation and dulling
  • The 100% inorganic formula is fully UV resistant. Does not yellow or cloud
  • Unmatched adhesion, chemical resistance, UV stability, and hydrophobic properties on all aluminum alloys, including magnesium
  • This coating is excellent for outdoor applications.
  • Tack free after 15-30 minutes
  • Fully cured after 24 hours

NOTE: No catalyst is required for this product. A 325-mesh screen (SE-277) is required for this color. Do not store this product in direct sunlight.

Heat resistance
Chemical resistance
Corrosion protection
UV protection

Technical Data

Filter sieve

325 (Artikel SE-277)

Drying

Air Curing

Drying Plan

15-30 min. tack free / 24 hours 100% full cure

Layer thickness

1.3-6.5 μm

Gloss Level

160 IU

Density

0.88 g/ml

Proportion of solid components

45%

Viscosity

3 cP

Hardness Grade Gouge (ASTM D3363)

7H

Scratch Hardness (ASTM D3363)

7H

Crosscut Adhesion (ASTM D3359)

5B

Flexibility (Mandrel Bend ASTM D522)

100%

Impact Performance Direct/Indirect (ASTM D2794)

18.08 Nm / 18.08 Nm

Color Stability (max. Temperature)

up to 150°C

Temperature Stability (max.)

up to 150°C

Testing procedures

All results are based on blasted steel coated with the recommended film thickness and cured according to the recommended curing cycle.

Gloss levels are measured at a 60° angle. Deviations from the recommended conditions lead to different results. Gloss is influenced by the quality of pretreatment and the spraying technique.

Viscosity measured under ambient conditions (air temperature, relative humidity) at the time of manufacture.

Recommended curing temperature:

  • Please refer to the curing cycle specifications provided for each Cerakote product.

The maximum temperature is the temperature up to which the paint or coating remains stable.

Chemical resistance testing: The results refer to color changes according to the CIE76 formula. The results range from:

  • Excellent: ∆E change <2.5 (★★★★)
  • Good: ∆E change <3.0 (★★★☆)
  • Satisfactory: ∆E change <3.5 (★★☆☆)
  • Poor: ∆E change <4.0 (★☆☆☆)

The test parameters are as follows:

  • Hardness or pencil hardness tests are measured from soft to hard as follows: 9B, 8B, 7B, 6B, 5B, 4B, 3B, 2B, B, HB, F, H, 2H, 3H, 4H, 5H, 6H, 7H, 8H, 9H. 9H is the highest hardness level.
  • SG-100 only: Hardness test Method A — An X-cut is made through the coating down to the substrate; a self-adhesive tape is applied over the cut and then removed. Adhesion is qualitatively rated on a scale from 0 to 5.
  • Adhesion is measured on a scale from 0B, 1B, 2B, 3B, 4B, 5B, with 5B being the highest achievable rating.
  • Flexibility or bend test on a conical mandrel: “100% resistance” is the highest achievable rating and means the coating showed no cracks or flaking.
  • Impact resistance (direct/indirect) is measured on a scale from 0 Nm to 18.08 Nm, with 18.08 Nm being the highest achievable rating.
